Gem80 is a qmk/via wireless mechanical keyboard.
Features: TKL custom mechanical keyboard QMK/VIA compatibility 1000Hz polling rate Aluminum chassis & PC bottom case Omni-mount design for customizing the keyboard's sound and feel
Edition choices in this listing: Base; Tri-mode.
Colors choices in this listing: Inca Rose; Mystic Indigo; Obsidian Black.
Switch Set choices in this listing: Not Included; Mint (+$15); Raspberry (+$15); Lemon (+$15); Panda (+$20).
Keycap Set choices in this listing: Not Included; Themed Keycaps (+$15).
Choose one complete configuration to specify the exact version. Color, switch and layout combinations have their own prices and availability; a choice offered on one version is not automatically included with another. The selected configuration identifies the product supplied, including any explicitly selected accessories.
Accessory choices marked None or Not Included exclude that item. Select an explicitly included accessory combination if you need the additional parts shown in the gallery. This distinction is particularly important for a base keyboard or barebones configuration, where switches and keycaps must be checked separately.
Specifications
- Layout: ANSI 80%/TKL
- Number of Keys: 88
- Switch Type: Normal-profile
- Stabilizer Type: Plate Mounted
- Mount Type: Gasket & Top
- Hot-swappable Support: Yes (3/5 pin MX-style)
- N-key Rollover Support: Yes
- Backlight: South-facing RGB-LED
- Backlight Modes: 40+
- Compatible System: macOS/Windows/Linux/Android/iOS
- Operating Environment: -10 to 50℃
- MCU: ARM STM32F072
- RF: NRF52810 (tri-mode)
- Wired Polling Rate: 1000Hz
- 2.4GHz Polling Rate: 1000Hz (tri-mode)
- Bluetooth 5.0 Polling Rate: 125Hz (tri-mode)
- Top Case: Aluminum
- Bottom Case: PC
- Plate Material: Fr4
- Long 141.3 mm (5.56 inches)
- Wide 358.1 mm (14.10 inches)
- Back Height 36.7 mm (1.44 inches)
- Front Height 21.5 mm (0.85 inch)
- Weight 1120 grams (2.47 pound)
- Type Angle 6º
- Battery Capacity: 4000mAh
- Working Time (all lights on): 24~45 hours (lab test result)
- Working Time (homing bars only): 34~70 hours (lab test result)
- Working Time (all lights off): Up to 330 hours (lab test result)
